Pioneer DJ OPUS-QUAD: 4-Channel DJ Standalone Controller

About the Pioneer DJ OPUS-QUAD: 4-Channel Standalone DJ Controller

The new Pioneer DJ OPUS-QUAD professional all in one DJ system puts you in control of the music, like the conductor of an orchestra.  Creating harmony between beautiful design and musical playability, it includes new and evolved features such as standalone 4 decks playback.  All this combines to provide a spectacular DJ experience that you can harness to inspire your audience in any space or location.

Harmony between brand new beautiful design and musical playability:

The OPUS-QUAD introduces a completely fresh approach to DJ equipment that harmonizes design and playability.  Raising the level of elegance in musical direction and the space the music fills, it helps create a special experience for your audience.

Standalone 4 decks playback for versatile DJ performances:

The OPUS-QUAD offers standalone 4 decks playback for versatile DJ performances.  This means you can play 4 tracks on different decks simultaneously, cue up tracks in advance, or leave a deck free for dropping requests into your set at a moment’s notice, all through just 1 unit.  You can also assign a different color to each deck, which is matched by the jog ring illumination, so you'll always know which deck you're playing.

Support for multiple media sources to match different playing styles:

How do you like to play?  From USB thumb drives or huge SSD drives?  By plugging in your PC / mac that's running DJ software?  By connecting via WiFi to wirelessly play tracks from your smartphone using Rekordbox, or by using Rekordbox cloud direct play? You can draw from various music libraries through just 1 OPUS-QUAD and you can even pair a mobile device via Bluetooth / MD wireless technology, perfect if you want to quickly drop a request into your set.

Rapid and accurate track search, even from the biggest collections:

Find your tracks faster and more accurately than ever before through the freshly designed user interface and an electrostatic touch module.  No matter how big your music library is, you can use the 10.1" touchscreen to quickly search for songs via the keyboard or use playlist bank for quick navigation between playlists.  Through touch preview, you can even preview tracks while browsing.  The new smart rotary selector offers a joystick like experience through left / right, up / down, rotation, and push control. And the other browsing controls are neatly arranged around the selector so you can scour your music collection and preview and load tracks without moving your hand.

Optimized deck configuration and new smart cue:

Take control of the music through a slick deck layout that includes a deck display and 8 hot cue buttons above each full size jog wheel.  Through this arrangement, you don't need to switch your gaze when manipulating tracks or checking things such as the track information, parameter, and status of each function.  And through the new smart cue feature, you can automatically overwrite the current cue position through the recalled hot cues.  This makes it much quicker and more intuitive than ever before to use hot cues through one touch.  To use the smart cue function, 'overwrite current through hot cue' must be turned on in the utility setting in advance.

High quality pleasant sound that enhances the audience's experience:

Designed to meet the needs of the increasingly diverse DJ scene, the OPUS-QUAD produces high quality sound that's comfortable to listen to for long periods of time.  The configuration of the unit eliminates transmission loss and AD to opposite for conversion loss and it's loaded through a high quality 32 bits D / A converter from ESS Technology. As a result, wherever you play on the OPUS-QUAD, the entire venue is gently enveloped by a comfortable sound that enhances the spatial experience.

Easy to use professional effects:

The evolved effects on the OPUS-QUAD make it easy to add texture and tension to the music so you can hype up the crowd and personalize your sound through beat FX.  The XY pad makes it easy to control features such as FX bank and channel select, as its parameters and the cutoff frequency of the filter are Controlled by movement on the X and Y axis respectively, so you can blend both effects through a single finger.  Through the popular smooth echo feature, you can easily trigger an echo sound by moving a fader or knob you've pre assigned to apply the effect when it's turned on.

Zone output for playing different music in different spaces:

Thanks to the zone output, which can output sound that's separate from the master, you can play different music in different rooms from just 1 OPUS-QUAD.  For example, you could connect a phone to the unit via Bluetooth and set a playlist of background music to play quietly in a bar area or a 2nd room where people are socializing while you mix tracks from a USB device in the main room.

Rekordbox and serato compatibility:

Plug and play compatibility for Rekordbox performance mode and serato DJ professional is included alongside the OPUS-QUAD.  You can simply plug in your PC / mac running either application to get started, there's no need for a license or subscription.  If you use Rekordbox you can also connect to it for IOS / android mobile app.  To use the system through Rekordbox for free, click to install the PC / mac version of the software.

Rekordbox link export:

Play tracks directly from your laptop as if it were a USB drive via Rekordbox link export mode.

Firmware update manager

You’ll be automatically notified when they become available.  You can download the manager here.

Smooth echo:

Assign the smooth echo effect to your choice from a selection of controls, e.g., a fader or pad.  Then, when you turn on smooth echo through its dedicated button, the echo will be triggered as soon as you move the relevant control.

2 microphone inputs:

The microphone input circuit produces crystal clear sound, even through a high input level.

Beat loop knob:

Using just 1 knob, you can turn on / off and change the length of a beat loop.

Main features:

• Supported music file formats: MP3, A and FLAC, WAV, AIFF, apple loss less
• File systems: EX and fat 16 and 32, HFS + (NTFS isn't supported.)
• Compatible DJ software: Rekordbox and serato DJ professional for mac / windows and IOS / android: hardware unlock
• MIDI control and USB record and plug and play and auto standby: yes

Specifications:

• Frequency range: 20 - 20000 hz
• Width: 925.7 mm
• Height: 142 mm
• Depth: 499.7 mm
• Weight: 13.2 kg
• Sampling rate: 44.1 kHz
• Power supply: AC 100 - 240 V, 50 / 60 hz
• Power consumption: 60 W
• Master DA converter: 32 bits
• A / D converter: 24 bits
• Signal to noise ratio
• USB: 114 dB
• Line: 96 dB
• Phono: 85 dB
• Microphone: 79 dB
• Distortion: USB and line: 0.0 %

Performance control:

• -Channels: 4-
• Deck control: 4 (USB storage device and DJ software control)

• Jog wheel: 206 mm
• Jog feeling: yes
• Sound color and beat FX: space, dub and echo, sweep, noise, crush, filter, delay, ping pong, spiral, reverb, trans, flanger, phaser, pitch, slip and roll, vinyl brake, helix
• Hot cues: 8 per deck
• Beat and manual loop and jump and sync and quantize and wave zoom and trim knob and EQ isolator: yes
• Microphone connection: XLR connector & 1 / 4" TRS jack
• Microphone EQ: 3 bands
• Talk over: microphone off / on / talk over slide SW
• Terminals; in and outputs: 2 lines and phonos and microphones and 1 master and zone and booth and phones (RCA and XLR connector & 1 / 4" and 3.5 mm stereo phone TRS and mini jack)
• USB: 3 type A and 1 B ports


Wireless LAN:

• Supported standards: IEEE 802.1 A / B / G / N / AC
• Frequency band used: 2.4 / 5 gHz

Bluetooth:

• Wireless system: Bluetooth version 4.2
• Maximum transmission distance: approximately 20 m in unobstructed circumstances.  (Transmission distances are a guideline.  The distance may change depending on the surrounding environment.)
• Frequency band used: 2.4 gHz
• Modulation method: FH-SS (frequency hopping spread spectrum)
• Compatible codecs: SB and AAC
