JL Audio C2-650X: 6.5" 60 W RMS 2-Way C2-Series Evolution Coaxial Speakers
About the JL Audio C2-650X: 6.5" 60 W RMS 2-Way C2-Series Evolution Coaxial Speakers
C2-Series systems deliver sparkling high frequency detail, smooth and powerful mid range and bass, thanks to real silk dome tweeters and precision engineered woofer designs. The C2-650X system features 6.5" (165 mm) woofers through mineral filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio's vast woofer design experience and advanced modelling systems. The 6.5" (165 mm) format is a direct fit in many vehicles. Multiple mounting patterns are provided on the woofer frame for easy installation into most vehicles that accept a 6.5" (165 mm) Speaker.
Tweeters are coaxially mounted and built through 0.8" silk dome diaphragms that deliver smooth, extended response, on and off axis. The small size of the C2-Series tweeter minimizes tweeter protrusion, allowing C2-Series Coaxials to fit behind most factory speaker grilles. Woofer grilles are included, each consisting of a black grille tray through satin silver accents and a black steel mesh grille through an electroformed JL Audio logo. Sold as a pair.
Specifications:
- Continuous power handling (RMS): 60 W
- Recommended amplifier power (RMS): 15 - 100 W / channel
- System efficiency: 91 dB @ 1 W / 1 m
- System nominal impedance: 4 Ω
- System frequency response: 59 hz - 22 kHz ± 3 dB
Coaxial physical specifications:
- Frame outer diameter: 6.5" / 165 mm
- Grille tray outer diameter: 6.8" / 174 mm
- Motor outer diameter: 3.2" / 80 mm
- Frontal Coaxial tweeter protrusion: 0.5" / 12 mm
- Frontal grille protrusion: 0.9" / 22 mm
- Mounting hole diameter: 5.6" / 141 mm
- Mounting depth: 2.4" / 62 mm
- Does not take into account mounting tabs
- Frontal Coaxial tweeter and grille protrusion measured from mounting surface
What's in the box:
- Two 2-Way Speakers and grilles and Crimpable female quick slides (0.2" / 5.2 mm and 0.1" / 2.8 mm) and JL Audio logo badges
- 8 self tapping screws (8 x 1 - 3 / 16") and speed clips
- Owner's manual
- Paper template
