Chauvet DJ SLIMPART6BTILS: LED Wash Light

About the Chauvet DJ SLIMPART6BTILS: LED Wash Light

Enjoy punchy Wash Lighting in a small form factor through SLIMPART6BTILS.  This compact tri color (RGB) LED fixture has control flexibility through ILS, DMX, and Bluetooth for programming directly from a smart phone or tablet.  Make an impact fast, create cohesive visuals, and save time running cables by power linking multiple units.

Features:

• Compact Wash Light through built in Bluetooth wireless technology
• ILS compatibility for use in the ecosystem (D FI USB sold separately)
• D FI USB compatibility for wireless master / slave or DMX control
• Control directly from a smart phone or tablet without any additional hardware.
• Easily set static colors or automated programs through the optional IRC-6 remote
• Compact built in automated programs via IRC-6 remote, master / slave or DMX
• Save time running cables and extension cords by power linking multiple units.
• Fits best in the CHS-30 VIP gear bag

Specifications:

• DMX channels: 3 / 7
• DMX connectors: 3 pins XLR
• Light source: 6 LED's (tri color RGB) 4.8 W, (2 A), 50,000 hours life expectancy

• Strobe rate: 0 - 20 hz
• Beam angle: 17 °
• Field angle: 33 °
• Operating frequency: 2.4 gHz
• Illuminance: 1754 LUX @ 2 m
• Power linking: 25 units @ 120 V; 38 units @ 230
• Input voltage: 100 - 240 VAC, 50 / 60 hz (auto ranging)
• Approvals: CE, ROHS, FCC
• Power and current: 21 W, 0.3 A @ 120 V, 60 hz; 21 W, 0.3 A @ 230 V, 50 hz
• Bracket mounting hole: 13 mm
• Optional controllers: IRC6, ILS command
• Bluetooth version: 4.2
• Maximum unobstructed distance: 150 FT (25.7 m)
• Maximum output current: 8 A (25 units @ 120 V) (38 units @ 230 V)
• Weight: 2.2 lbs (1 kg)
• Size: 10.4 x 7.6 x 3" (265 x 218 x 76 mm)

What's included:

• SLIMPART6BTILS
• Power cord
• Quick reference guide
