Chauvet DJ ELLIPSOIDAL-50Z: LED Gobo Spot Light

About the Chauvet DJ ELIPSOIDAL-50Z: LED Gobo Spot Light

The ELLIPSOIDAL-50Z is an LED Gobo Spot Light that shines a hard edged, warm white Spot and features DFi USB compatibility for wireless master / slave or DMX control.  Manual zoom gives you the flexibility to project from any distance and its framing shutters let you easily alter and control the projected beam.  The ELLIPSOIDA-50Z includes holders for glass and steel Gobos as well as a gel frame.  You can operate it in standalone mode eliminating the need for DMX control and you can save time running extension cords by power linking multiple units.

Features:

• LED ELLIPSOIDAL shines a hard edged, warm white Spot in any direction
• Easily highlight areas by altering the projected beam through framing shutters
• Flexibility to project from any distance using the manual zoom
• DFi USB compatibility for wireless master / slave or DMX control
• Powercon compatible power input / output connections for power linking
• Flicker free operation suitable for on camera use
• Includes holders for glass and steel gobos and a gel frame
• Save time running extension cords by power linking multiple units
• Eliminate the need for DMX control through standalone operation
• Available in black or white

Specifications:

• DMX channels: 1 / 3
• DMX connectors: 3 pin XLR
• Light source: 1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy
• Strobe rate: 0 - 29 hz
• PWM frequency: 1.2 kHz
• Illuminance: (20 °): 7910 LUX @ 2 m (39 °): 2710 LUX @ 2 m
• Power linking: 16 units @ 120 V; 26 units @ 230 V
• Input voltage: 100 - 240 VAC, 50 / 60 hz (auto ranging)
• Power and current: 59 W, 0.5 A @ 120 V, 60 hz / 63 W, 0.3 A @ 230 V, 50 hz
• Gobo size: D (53.3 mm outside, 43 mm image, 2 mm maximum thickness)
• Zoom angle: (manual): 20 - 39 °
• Weight: 9.2 lbs (4.2 kg)
• Size: 18.9 x 6.2 x 15" (480 x 157 x 381 mm)
• Approvals: CE
• Color temperature: 3500 K
• Gel frame size: 5.5"
• Optional controllers: DFi USB

What's included:

• Steel and glass Gobo holders
• Gel frame
• Power cord
• Hanging bracket and mounting hardware
