BlackVue DR970X-2CHLTE-PLUS-64: 2-Channel / Dual Dash Camera

About the BlackVue DR970X-2CHLTE-PLUS-64: 2-Channel / Dual Dash Camera

Seamless pairing:

Simply connect to your Dash Camera without leaving the BlackVue app.  Through seamless pairing, setting up your Dash Camera is a breeze.  Just power the Dash Camera, then easily connect from the BlackVue app and follow the simple instructions.  Whether you want to browse your Dash Camera's files and settings or connect your Dash Camera to the cloud seamless pairing makes everything easy and intuitive.

Best compression and high bitrate:

H.264 and H.265 codec support: the DR970X box plus-series features H.265, also called high efficiency video coding (HEVC), the leading standard in 4 K recording and broadcasting.  H.265 ensures the best video quality.  The more widely compatible H.264 is also supported.

Higher bitrate for uncompromising video quality: when using HEVC, the 4 K front Camera can record at a high bitrate of up to 60 MB per second, which lets the Camera deliver amazing artifact free image quality in even the most complex fast moving scenes.

Worried about large files over the cloud or WiFi: BlackVue's sub stream technology embeds quick play, under 5 MB, versions of the videos in the original files.  Quick play files allow for instant buffer free playback over the cloud or a WiFi connection.  If needed, you can also play the original full resolution videos for maximum quality.

Sleek interface:

Speaker: your Dash Camera tells you when it turns on, shuts down or detects errors.  Accelerometer: detects impacts to trigger event recording.  Enables parking mode when stationary for 5 minutes.  Automatically tags video files: while driving, the accelerometer (G sensor) detects impacts and sudden changes in speed.  While parked, your BlackVue also detects visual movements around your vehicles (in motion + impact detection mode).  Use the filters in the BlackVue app and viewer: BlackVue tags all videos (normal, event, parking mode, etc.), so that you can filter them and quickly find the ones you need in the BlackVue viewer (windows, mac OS, web) or the BlackVue app (android, iOS).

Free app and viewer:

Easily change your BlackVue configuration settings and browse your videos on your mobile or computer.  Through the BlackVue app, connect to your BlackVue to access files and check real time live view for easy setup of your Dash Camera.  Through the SD card viewer, connect your Dash Camera's micro SD card to your computer to view and backup footage in bulk, as well as export clips, remove sound, etc.

Your videos are safe:

Event files overwrite protection: Dash Cameras record in a loop, overwriting older files when the memory is full.  BlackVue can prevent event files (triggered manually or by impacts) overwriting.  Up to 50 files can be protected this way.  You can choose to allow new event files to overwrite past event files, thus keeping the latest 50.

Adaptive format free file management: this BlackVue developed file system improves recording stability and requires less micro SD card formatting.

SD card failure alert: your BlackVue detects as soon as the micro SD card fails and warns you via a "please check SD card" voice alert.

Specifications:

• Channel: 2CH
• Highlights: built in 4 g LTE, Sony starvis 2 image sensors
• Product dimensions; front: black / 137.6 (L) x 60.3 (W) x 43 (H) mm / 166 g; rear: black / 67.3 (L) x 28 (W) x 25 (H) mm / 25 g
• Rear camera connection: coaxial cable
• Memory support: micro SD card up to 512 GB
• Recording modes: normal recording, event recording (when impact is detected in normal and parking mode), manual recording and parking recording (when motion is detected)
• When using hardwiring power cable, ACC+ will trigger parking mode.  When using other methods, G sensor will trigger parking mode.
• Parking mode: yes (hardwiring cable included)
• Parking mode event voice notifications: yes
• Imaging sensor; front: starvis 2 CMOS sensor (approximately 8.4 M pixels); rear: starvis CMOS sensor (approximately 2.1 M pixels)
• Viewing angle; front: diagonal 146 °, horizontal 125 °, vertical 68 °; rear: diagonal 131 °, horizontal 107 °, vertical 55 °
• Resolution frame rate; front: 4 K (3840 x 2160) @ 30 FPS; rear: full HD (1920 x 1080) @ 30 FPS
• Frame rate may vary during WiFi streaming.
• Video codec: H.265 (HEVC) / H.264 (AVC)
• Image quality and bitrate front / rear; highest (extreme): 60 + 10 MBPS; highest: 25 + 10 MBPS; high: 12 + 8 MBPS; normal: 8 + 6 MBPS
• Format free: yes (adaptive)
• Event file overwrite protection: yes (up to 50)
• SD card failure alert: yes
• Scheduled reboot: yes
• Video file extension: MP4
• WiFi: built in (802.11 A.B.G.N.AC)
• Cloud compatible: yes

• GPS: built in (dual band: GPS, GLONASS)
• Microphone: built in
• Speaker: built in
• Impact sensor: 3 axis acceleration sensor
• LED indicators; front: recording LED, GPS LED, B / W / L (Bluetooth / WiFi / LTE) LED, front security LED; rear: security LED
• Button; touch sensor: pressing the touch sensor triggers manual recording depending on the firmware settings.
• Operation temperature: -20 ° C - 70 ° C (-4 ° F - 158 ° F)
• Storage temperature: -20 ° C - 70 ° C (-4 ° F - 176 ° F )
• High temperature cut off: approximately 70 ° C (167 ° F)
• Backup battery: built in super capacitor
• Input power: DC 12 - 24 V (3 pole DC plug (Ø 3.5 x Ø 1.1) to wires (black: GND / yellow: B+ / red: ACC)
• Power consumption hour; normal mode (GPS on / cloud on): average 590 mA / 12 V; normal mode (GPS on / cloud off): average 530 mA / 12 V; parking mode (GPS off / cloud on): average 430 mA / 12 V; parking mode (GPS off / cloud off): average 370 mA / 12 V
• Actual power consumption may vary depending on use conditions and environment.
• Model DR970X-2CHLTE-PLUS-64 should be used only in circuits that satisfy limited power source (maximum power consumption is to be less than 100 VA / 8 A).
• Certifications; front: FCC, ISED, CE, UKCA, RCM, TELEC, RoHS, WEEE, KC; rear: FCC, ISED, CE, UCKA, RCM, RoHS, WEEE, KC
• Software; BlackVue viewer; windows 7 / higher, mac sierra OS X (10.1) / higher; BlackVue web viewer; chrome 71 / higher, safari 13.0 / higher
• BlackVue application: android 8.0 / higher, iOS 13.0 / higher
• Others: Built in 4G LTE module compatible alongside nano sim; frequency bands: B2, B4, B12
• Bluetooth: built in (V2.1 + EDR / 4.2)
• LTE: built in (sim card included)

Recording time:

 What's in the box:

• Front Camera
• Rear Camera
• Quick start guide
• Cable clips (8 EA)
• Micro SD card
• Micro SD card reader
• Spare mount sticky pads
• Coaxial cable (6 m)
• Hardwiring power cable
• Cigarette lighter power adapter
• Pry tool
• Sim eject tool
• BlackVue sim card (including NA model only)
