AudioControl PNW-65CS2: 6.5" PNW-Series Component Set
- In stock, ready to ship
Specifications:
- Crossover type: 2nd order linkwitz riley
- DC resistance (RE): 2.3 ohms
- Filter type: HP / LP
- System frequency response (FS): 60 - 20 K hz
- XO frequency: 3.5 kHz HP / LP
- Slope (octave): -12 dB
- Tweeter voice coil diameter: 20 mm
- Midrange voice coil diameter: 35 mm
In the box:
- PNW-65CS2
- Manual
- Warranty
Dimensions:
- Overall diameter (without grille) 6.5" / 166 mm
- Cut out diameter: 5.6" / 142 mm
- Mounting depth: 2.4" / 60 mm
- Mounting height (without and including grille): 0.2" / 5.2 mm, 0.9" / 22 mm
- Motor diameter (including cover): 4.6" / 117 mm
- Grille overall diameter: 7.1" / 179 mm
Dimensions for tweeter:
- Overall diameter: 2.1" / 54 mm
- Cut out diameter: 1.9" / 47 mm
- Mounting depth: 0.6" / 16 mm
Orders are typically processed and Shipped within 1 - 2 business days. Delivery usually takes 7 - 15 business days via Canada post, FedEx, or UPS.
