Wavtech LINK500.4MINI: 4 x 125 W RMS Class-D 4-Channel MINI Amplifier
- In stock, ready to ship
A pair of new front speakers and a subwoofer is one of the most common aftermarket audio upgrades. The LINK500.4MINI is the perfect Amplifier for this application. When used in 3-Channel mode, the Amplifier can produce 125 W x 2 for the main speakers and 250 W x 1 for the subwoofer, so it won't lack for power. Speaking of the subwoofer, Channels 3 / 4 have a 1 band paragraphic EQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance.
The LINK500.4MINI has Wavtech's LINK4 built in, through internal loading and the ability to handle up to 40 V of high level input. It also has fully adjustable high and low pass crossovers. For factory audio systems where no full range signal is present, the LINK500.4MINI has built in summing, so it can handle that internally, without the need for an outboard processor. Like all Wavtech amplifiers, the LINK500.4MINI is start / stop system compatible.
Features:
- 500 W 4-Channel Amplifier
- 75 W x 4 @ 4 ohms
- 125 W x 4 @ 2 ohms
- 250 W x 2 @ 4 ohms BTL
- Small footprint only 9.2" x 4.5" x 1.7"
- Adjustable parametric EQ (Channels 3 / 4)
- Variable subsonic filter (Channels 3 / 4)
- Variable high / low pass crossover (-12 dB / OCT)
- Remote level control (RLC) including optional LINKRC (Channels 3 / 4)
- Built In summing including level trim adjustment
- Start / stop system compatible
- Differential balanced inputs
- Variable gain adjustment including clip LED
- Auto turn on via DC offset or audio signal detect
- OEM load detect compatible
- Locking detachable high level speaker terminals
- Professional grade panel mount RCA's
- Compact aluminum chassis including detachable mounting tabs
