Quest Commercial PR-130BT: 130 W 6-Zones Bluetooth Mixer / Amplifier

About the Quest Commercial PR-130BT: 130 W 6-Zones Bluetooth Mixer / Amplifier

The Quest Commercial PR130BT is a 130 W all in one Mixer / Amplifier including Bluetooth, and the ultimate solution for sound distribution systems in small to medium sized Commercial premises, delivering the best and highest quality audio at an affordable price.  It also has a constant voltage power Amplifier allowing use at 70 / 100 V or at low impedance of 4 ohms.

The PR-130BT can deliver a power of 130 W, and the PR-240BT a power of 240 W. They offer 6 inputs channels (terminal block / RCA) through independent level controls to facilitate the connection of sound sources.

It has a telephone paging input for connection to a telephone system for announcement, a digital remote microphone input on RJ45 for connection to a RM6, 6-Zones paging microphone.  A music on hold feature is also available for businesses wishing to enhance their customers' telephone experience.  When you connect these Mixers to a telecommunications system, customers can listen to music or pre recorded messages while they wait.

Features:

• Designed for the most common Commercial installation requirements.
• Ideal for background music, microphone, and paging through the ability to connect 6 external sources.
• Industry standard connectors to make installs fast and efficient.
• Front panel controls to easily manage source and master volumes through bass & treble control.
• 2 U rack mountable (ears included).
• Built in media player through Bluetooth, USB / SD MP3 player, FM & recording.
• 4 balanced microphone / line inputs, through 48 V phantom.
• 2 AUX in, 1 line and link out, all on RCA connectors.
• 6-Zones out through discrete volume control and paging microphone input on RJ45 (not included here).

• Optional RM6: 6-Zones paging microphone station.
• Tel paging, and music on hold (MOH) through volume controls.
• Priority through ducking level control & channel selector.
• Contact closure to record / play messages.
• Phoenix / euro connectors.
• CSA / UL approved.
• Class-D & switching power supply: PR-130BT @ 120 V / 2.2 A; PR-240BT / A @ 120 V / 3.8 A
• All in one solution for Commercial and industrial applications.
• Bass & treble controls.
• 3 years warranty.

Specifications:

• Total rated power output: 130 W
• Speaker output: 4 Ω; 70 / 100 V
• Input connectors: CH 1 - 4: microphone / line on balanced 3 conductor phoenix connectors through phantom power; AUX: 2 line inputs on stereo RCA
• Speaker output connectors: 6-Zones outputs for high Z (70 / 100 V) only, or single output for 4 Ω; 70 / 100 V
• Frequency response: 80 hz - 18 kHz (± 3 dB)
• Tone control: 100 hz - 10 kHz; ± 12 ± 3 dB
• S / N ratio: < 90 dB
• THD (1 kHz): < 0.5 %
• Crosstalk at all control maximum: - 70 dB at 1 kHz
• Phantom power: + 48 VDC
• Protection: over current and temperature / under voltage / DC fault
• Power supply: 120 V AC, 50 - 60 hz
• Carton dimensions (W x D x H): 20.7 x 16.5 x 7.6" (525 x 420 x 193 mm)
• Weight (net): 22.1 lbs (10 kg)
